Solutions for 10.1 and 10.4 Inch LCD Screen

The size of 10 inches is actually rare in the market, and it is more common to be 10.1 inches or 10.4 inches. Therefore, if customers choose a 10-inch screen, merchants often directly recommend a 10.1-inch or 10.4-inch. The main difference between 10.1 and 10.4 inches is the resolution, 10.1 inches is widescreen and 16:9 structure, while 10.4 inches is a 4:3 square screen structure.

The 10.1-inch LCD was actually a standard size for consumer screens before. And the 10.1 HD TFT LC color monitor is a popular product in the market. With the development of the industry, many LCD screen manufacturers are now gradually transforming 10.1 inches into an industrial size, and 10.4 inches has always been a standard industrial size. These two sizes currently have many models to choose from, each with its own characteristics. Below we provide you with a selection scheme for different parameters of the LCD screen.

Resolution of 10.1 and 10.4 LCD monitors

The first is the issue of the resolution, which determines the structure of the screen. Common resolutions of 10.1 inches are 1024*600, 1280*800, and 1920*1200. Common resolutions of 10.4 inches are: 640*480, 800*600, 1024*768. If you need to meet widescreen high-definition display, you can choose 10.1-inch 1920*1200. If you need a square screen with a high-definition display, you can choose the 1024*768 resolution of the 10.4 LCD. Generally, customers who have no requirements for resolution can choose 10.1-inch 1280*800 and 10.4-inch 800*600 screens. These two resolutions are used more, and the price/performance ratio will be much higher.

Interfaces of 10.1 and 10.4 LCD

The interface type of the 10.1-inch LCD screen is the largest size compared to other sizes of screens. It covers four types of interfaces: RGB, LVDS, MIPI, and EDP, which are commonly used. These types also have related interface transfer driver boards that can be matched.

The interface of the 10.4 LCD screen is relatively simple compared with the 10.1 inches, and it is basically an LVDS interface. The low-resolution 6400*480 has an RGB interface, but the 640*480 resolution is basically not chosen by new customers, usually 800*600 and 1024*768, these two resolutions are basically the same LVDS interface.

Brightness of 10.1 and 10.4 LCD monitors

Terminal equipment needs to be used outdoors and operate in direct sunlight. Low brightness is absolutely impossible. Therefore, the selection of the right TFT LCD monitor with the right brightness for a specific intended application is crucial for meeting the customers’ need and ensuring satisfaction in wholesale TFT LCD distribution. At this time, we need to choose an industrial screen with high brightness and wide temperature. The 10.1-inch highlight screen options are relatively few, but you can also change the backlight brightness of the LCD screen by highlighting. There are many choices for 10.4-inch medium and high-brightness screens. There are several high-brightness screens for Japanese and Taiwanese screens to choose from. 800*600 and 1024*768 resolutions also have suitable high-brightness screens to choose from. For details, you can consult the official website customer service information.

Operating temperature of 10.1 and 10.4 LCD monitors

The working temperature of the LCD screen determines the application environment of the LCD screen. Most of the 10.1-inch screens can meet the working temperature of -20~+70, the high-resolution 1920*1200 can only reach -10~+60, and the 1280*800 resolution can reach the highest -40~+85 Operating temperature.

10.4 LCD screen is a standard industrial size, so most of them are -30~+80. Most of the 10.4-inch products produced by manufacturers are -20~+70, and the minimum working temperature of Japanese brands can be -40~+85. For equipment that has certain requirements for temperature, it is necessary to use a Japanese screen.
